Used Pinnacle Stair Lift

Plus Shipping

Add to Cart

Product Specifications

Drive TypePolymer Worm & Worm-Rack
Battery PoweredYes
Self InstallableYes
Basic Installation IncludedNo
Standard Capacity350 lb
Max Track Length, Standard12'
Max Track Length, Optional70'
Track MaterialAluminum
Seat Width18.75"
Seat Depth16"
Swivel SeatYes
Flip-Up SeatYes
Flip-Up ArmrestsYes
Constant Pressure ControlsYes
Footrest Safety SensorYes
Unit Footprint, Non-Folded23.75"
Unit Footprint, Folded11"
Track Footprint6.5"
Warranty1 Year Parts Only
Call Stations IncludedOptional - Depends on inventory available
Digital Diagnostics DisplayNo
Key LockNo

Harmar's Pinnacle stair lifts have never been more affordable, because now you can save even more by buying a used Pinnacle unit!

When the seat is folded up, the Pinnacle only takes up 11 inches of space on your stairway, so maneuvering around the stair lift is a snap!

This energy efficient stair lift is low-maintenance and powered by a DC battery which recharges during use, ensuring that if your power goes out, you always have enough juice to make one more trip so you can get somewhere safely!

Used Pinnacle stair lifts must be installed by our technicians.

Available Upgrades

  • Subject To Availability

    • Used stair lift inventory fluctuates daily.
      Please call for current availability.
         +$0.00   option_name
  • Weight Capacity

    • 350 lb.   +$0.00   No Image
  • Track Length

    • Up to 7' of track is included free with your lift.   +$0.00   No Image
    • Additional Track Per Foot - Up To 70' Total   +$70.00   No Image
  • Options

    • Call/Send Remotes   +$199.00   No Image
  • Seat Upholstery Color

    • Please Call For Color Availability   +$0.00   Light Almond Seat Color For Pinnacle
  • Orientation (looking UP the staircase)

    • The stair lift will be on the left   +$0.00   No Image
    • The stair lift will be on the right   +$0.00   No Image
  • Installation Special Cases

    • Installation On Concrete, Steel, or Tile Stairs   +$300.00   No Image
    • Installation In Remote or Limited Access Location   +$285.00   No Image
  • Installation

    • Self Installation   +$0.00   No Image
    • Nationwide Installation   +$575.00   No Image
    • Nationwide Measurement and Installation   +$725.00   No Image
  • Permit and Inspection

    • Permit and Inspection (Required in Alabama)   +$285.00   No Image
    • Permit (Required in Kentucky)   +$87.50   No Image
Product Video
